SRSC4545H1

The SRSC4545H1 Reach Stacker has an operating weight of 45T and a rated power of 265 kW/2100rpm

Download the SRSC4545H1 brochure HERE

Engine model VOLVO TAD1151

Operating weight 45 T

Compare Find a dealer

Engine
Emission standard	Stage Ⅲ
Engine model	VOLVO TAD1151
Max. torque	1780/1260 Nm/rpm
Rated Capacity	265 kW/2100rpm
Rated Capacity	45 T
Operation Range
Front Tyre Distance	3060 mm
Gradeability (unloaded/loaded)	26/17 %
Hydraulic System Pressure	260 bar
Max Descending Speed (unloaded/loaded)	360/280 mm/s
Max Hoisting Speed (unloaded/loaded)	400/220 mm/s
Max Travelling Speed (unloaded/loaded)	20/15 mm/s
Min. Ground Clearance	420 mm
Min. Turning Radius	10600 mm
No. of Stack	5 (8'6")
Overall Weight	96.5 T
Rear Tyer Distance	3120 mm
Tyre	21.00-35 36PR
Dimensions
20' Container Aile Width	14500 mm
40' Container Aile Width	15200 mm
Overall Height	5230mm
Overall Length	13270mm
Overall Width	6053-12185 mm
Wheel Base	420mm
Performance
Axle Model	KESSLER D106 PL341
Transmission	DANA 15.5HR36000
Spreader
Application	ISO20'/40'/45'container
Inclination Angle	0~50 deg
Shift Distance	±800 mm
Slewing Angle	+105/-195 deg
Spreader Model	SDJ450FA
Weight	7.8 T
Boom
Max Hoisting Height	13600 mm
