STH844A

SANY STH844A has a max. Rated Capacity of 3.63 T, 9150 mm maximum Reach and a max Lift Height of 13400mm

Download the STH844A Brochure HERE

Engine model CUMMINS QSF3.8 T4F 97kW

Operating weight 3.63 T

Compare Find a dealer

Engine
Emission standard	Stage Ⅳ
Engine model	CUMMINS QSF3.8 T4 55kW
Max. torque	400/1300 Nm/rpm
Rated power	55/2200 Kw/rpm
Operation Range
Capacity at Max. Height	2.722 T
Capacity at Max. Reach	0.68 T
Gradeability (Load)	74.9 %
Levering Angle	±10 deg
Lifting Height	13400 mm
Max Descending Speed (unloaded/loaded)	15/13 s
Max Hoisting Speed (unloaded/loaded)	13/10.5 s
Max Travelling Speed (unloaded/loaded)	20 km/h
Maximum Reach	9150 mm
Min. Ground Clearance	430 mm
Min. Turning Radius	4300 mm
Pitch Angle	70/-7 deg
Rated Capacity	3.63 T
Tyre	13.00-24-16PR
Dimensions
Load Center	610 mm
Overall Height	2510 mm
Overall Length	6158 mm
Overall Weight	11600 kg
Overall Width	2466 mm
Performance
Axle Model	DANA 212HY/223
Gearbox Model	Dana 1104FVDT12366
Fork
60in Fork - Adjustment Range	676~1829
60in Fork - Size (Length x Width x Thickness)	1524 x 152 x 60
72in Fork - Adjustment Range	694~1829
72in Fork - Size (Length x Width x Thickness)	1829 x 152 x 60
Rotate - Adjustment Range	354~1524
Rotate - Size (Length x Width x Thickness)	1524 x 152 x 60

Intelligent
Weight indicator system
GPS fleet management system
Horizontally move function

Reliable
Reliable boom and steel structure, pass strict test. 74 HP for option, no DEF tank, simple and reliable

Serviceability
Spacious service room, easy to access. Key component using American local brands.
