|Engine model||CUMMINS QSM11|
|Max. torque||1674/1400 Nm/rpm|
|Rated Capacity||250/2100 kW/rpm|
|Balance Weight Moveable Distance||-|
|Front Tyre Distance||3033 mm|
|Gradeability (unloaded/loaded)||39/32 %|
|Hydraulic System Pressure||260 bar|
|Max Descending Speed (unloaded/loaded)||360/300 mm/s|
|Max Hoisting Speed (unloaded/loaded)||420/250 mm/s|
|Max Travelling Speed (unloaded/loaded)||25/21 km/h|
|Min. Ground Clearance||350 mm|
|Min. Turning Radius||8000 mm|
|No. of Stack||5 (9'6" / 8'6")|
|Overall Weight||72 T|
|Rated Capacity||45 T|
|Rear Tyer Distance||2790 mm|
|20' Container Aile Width||11300 mm|
|40' Container Aile Width||13600 mm|
|Overall Height||4770 mm|
|Overall Length||11340 mm|
|Overall Width||6053-12185 mm|
|Wheel Base||6000 mm|
|Axle Model||Kessler D102 PL341|
|Gearbox Model||DANA 15.5HR36000|
|Shift Distance||±800 mm|
|Slewing Angle||+105/-195 deg|
|Inclination Angle||0~60 deg|
|Max Hoisting Height||15100 mm|
Dynamic Anti-Rollover Protection Technology
Adopt intelligent control technology, detect equipment's real-time working parameters, and automatically adjust the operating status under dangerous conditions to prevent rollover. It can achieve safe and worry-free operation.
Anti-collision Technology of the Spreaders while Revolving
Intelligent control of the positions of spreaders and booms can effectively prevent collision among the spreader, frame, and boom, avoiding accidents by faulty operation and greatly reducing labor intensity.
Automatic Fire Extinguishing Technology
The pipeline network automatic fire extinguisher with a strong spray can realize fire alarm, antiflaming, and fire extinction functions. The fireproof performance is steady and reliable.
Solid Tyre Suspension Technology
Provide solid tyre flexible damping system according to customers' needs to achieve safer operation and lower maintenance cost. Combine with flexible suspension technology, it significantly reduced the shocking load, raised operation comfort and prolonged component longevity.
Automatic Braking Technology upon Reversing
Adopting technologies like laser scanning and graphic identification, the machine can precisely detect people or obstacles within the driving route and then brakes automatically to prevent accidents. It is highly intelligent with high safety.
Reliable Structure Design
Designed by China and Germany together, the equipment is assured to be highly reliable and endurable by adopting full-digit prototype design system, going through FEA, dynamics simulation analysis, as well as strict endurance and vibration tests.
Reliable Power System
Using world-famous brand engines like VOLVO and CUMMINS which are reliable in quality and strong in power, combining the advanced power matching and control technology, the equipment is greatly optimized in dynamic performance. Scientific and appropriate protection for the engine and gearbox will significantly prolong their longevity.
